NG-MEDIUM
NG MEDIUM is an SRAM-based FPGA developed by NanoXplore, sharing the same programmable architecture as the radiation-hardened NG-MEDIUM family. The device integrates a matrix of 4-input Look-up Tables with LUT extenders for wider operations, configurable DFF, Coarse Grain Blocks with user-configurable memories, and dedicated Digital Signal Processing units. Optimized for cost-sensitive applications, NG-MEDIUM delivers high logic density and flexibility for industrial, automotive, and other high-reliability markets.
See the documentation ↗
Proven resilience for the harshest environments, from orbit to the edge
Scalable performance and flexibility to meet all your system’s needs
Detailled specifications to ensure optimal performance in every environment
DeviceNX1H35S
Capacity
- ASIC Gates550 000
Logic Modules
- Register32 256
- LUT-434 272
- Carry8 064
Embedded RAM2,856Mb
- DPRAM2,688K
- Core Register File168
- Core Register File Bits168K with ECC
Clocks24
Additional Features
- SpaceWire link PHY (8 IOBs)16
- DDR2 PHY (11 IOBs)16
- DSP Blocks112
- SpaceWire link I/F 400Mbps1
Inputs / Outputs — I/O banks13
Packages - User I/Os
-FG625 27*27mm / 1mm374
Main Features
- 28 nm STMFDSOI process technology.
- 12-bit ADC, 13-bit DAC.
- 4-Input Look-up tables.
- LUT expender to support up to 16 bits boolean functions.
- High performance carry chains.
- Advanced interconnect network to support random logic and coarse grain block functions.
- DSP Blocks for complex arithmetic operations.
- User memories with variable width and depth.
- Configuration modes: JTAG, Parallel 16 bits, Master Serial SPI, SpaceWire, Flash and UART.
- Integrated Space Wire interface available for user applications.
- Dedicated lowskew distribution network for clock, reset and load enable signals.
- On-chip thermal sensor.
Input / Output Features
- Multi voltage I/O support from 1.2V to 3.3V.
- Cold sparing support.
- Programmable output drive to support multiple industry standards.
- Embedded logic to support DDR2, DDR3 and DDR4.
- Up to 1.6 Gbps maximum I/O support for SSTL, HSTL and POD standards.
- LVDS compatible mode.
- All pins support 2000V of ESD-HBM.
- Embedded logic to support Space Wire Data Strobe encoding.
- Programmable delay lines on complex I/O pins.
- Programmable resistive termination on complex I/O pins.
Radiation Hardened
- Radiation hardening by design in configuration memories and registers.
- SEU immune up to LET > 60MeV.cm2/mg.
- Total ionizing dose > 50Krads (Si).
- Embedded EDAC for user memory mitigation.
- Embedded configuration memory scrubbing.
- Fast automatic memory configuration repair.
- Embedded bitstream integrity check (CMIC).
